Product Summary
The ADUC812BS is a fully integrated 12-bit data acquisition system incorporating a high performance self-calibrating multichannel ADC, two 12-bit DACs and programmable 8-bit(8051-compatible) MCU on a single chip. The programmable 8051-compatible core of ADUC812BS is supported by 8K bytes Flash/EE program memory, 640 bytes Flash/EE data memory and 256 bytes data SRAM on-chip. Normal, idle and power-down operating modes for both the MCU core and analog converters allow for flexible power management schemes suited to low power applications. The part is specified for 3 V and 5 V operation over the industrial temperature range and is available in a 52-lead, plastic quad flatpack package.
Parametrics
ADUC812BS absolute maximum ratings: (1)Intelligent Sensors (IEEE 1451.2-Compatible); (2)Battery Powered Systems (Portable PCs, Instruments, Monitors); (3)Transient Capture Systems; (4)DAS and Communications Systems.
Features
ADUC812BS features: (1)8-Channel, High Accuracy 12-Bit ADC; (2)On-Chip, 40 ppm/C Voltage Reference; (3)High Speed 200 kSPS; (4)DMA Controller for High Speed ADC-to-RAM Capture; (5)Two 12-Bit Voltage Output DACs; (6)On-Chip Temperature Sensor Function; (7)8K Bytes On-Chip Flash/EE Program Memory; (8)640 Bytes On-Chip Flash/EE Data Memory; (9)On-Chip Charge Pump (No Ext. VPP Requirements); (10)256 Bytes On-Chip Data RAM; (11)16M Bytes External Data Address Space; (12)64K Bytes External Program Address Space; (13)12 MHz Nominal Operation (16 MHz Max); (14)Three 16-Bit Timer/Counters; (15)32 Programmable I/O lines; (16)High Current Drive Capability—Port 3; (17)Nine Interrupt Sources, Two Priority Levels; (18)Specified for 3 V and 5 V Operation; (19)Normal, Idle and Power-Down Modes.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADUC812BS |
Analog Devices Inc |
IC ADC 12BIT MULTICH MCU 52-MQFP |
Data Sheet |
Negotiable |
|
||||||||||||||||
|
ADUC812BS-REEL |
Analog Devices Inc |
IC MCU 8K FLASH ADC/DAC 52MQFP |
Data Sheet |
Negotiable |
|
||||||||||||||||
 |
ADUC812BSZ |
|
IC ADC 12BIT MULTICH MCU 52-MQFP |
Data Sheet |
|
|
||||||||||||||||
|
ADUC812BSZ-REEL |
|
IC MCU FLASH 12BIT ADC 52MQFP |
Data Sheet |
|
|
||||||||||||||||
