Product Summary

The AD603AR is a low noise, voltage-controlled amplifier for use in RF and IF AGC systems. It provides accurate, pin-selectable gains of -11 dB to +31 dB with a bandwidth of 90 MHz or +9 dB to 51+ dB with a bandwidth of 9MHz. The AD603AR can drive a load impedance as low as 100 Ω with low distortion. For a 500 Ω load in shunt with 5 pF, the total harmonic distortion for a ±1 V sinusoidal output at 10 MHz is typically-60 dBc. The peak specified output is ±2.5 V minimum into a 500Ω load. The applications of the AD603AR are RF/IF AGC amplifiers, Video gain controls, A/D range extensions, Signal measurements.

Parametrics

AD603AR absolute maximum ratings: (1)Supply Voltage ±VS:±7.5 V; (2)Internal Voltage VINP (Pin 3):±2 V Continuous,±VS for 10 ms ; (3)GPOS, GNEG (Pin 1 and Pin2):±VS; (4)Internal Power Dissipation:400mW; (5)Operating Temperature Range:-40℃ to +85℃; (6)Storage Temperature Range:-65℃ to +150℃; (7)Lead Temperature (Soldering, 60 sec):300℃.

Features

AD603AR features: (1)Linear-in-dB gain control; (2)Pin-programmable gain ranges; (3)-11 dB to +31 dB with 90 MHz bandwidth; (4)9 dB to 51 dB with 9 MHz bandwidth; (5)Any intermediate range, for example -1 dB to +41 dB with 30 MHz bandwidth; (6)Bandwidth independent of variable gain; (7)1.3 nV/√Hz input noise spectral density; (8)±0.5 dB typical gain accuracy.
