AD606JR

50 MHz, 80 dB, Demodulating Logarithmic Amplifier, 16-SOP, Adjustable Output Amplitude

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~100.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~100.00

PartNumber:: AD606JR

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. chen's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-19

From Other Seller

Part Number:AD606JR
US $1.00 - 100.00
A50L-0001-0175

US $100.00 - 100.00 / Piece
(0) Remove
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD606JR is a complete, monolithic logarithmic amplifier using a 9-stage“successive-detection technique. The AD606JR provides both logarithmic and limited outputs. The logarithmic output is from a three-pole post-demodulation low-pass filter and provides a loadable output voltage of +0.1 V dc to +4 V dc. The logarithmic scaling is such that the output is +0.5 V for a sinusoidal input of –75 dBm and +3.5 V at an input of +5 dBm; over this range the logarithmic linearity is typically within ±0.4 dB. The applications of the AD606JR are Ultrasound and Sonar Processing, Phase-Stable Limiting Amplifier to 100 MHz, Received Signal Strength Indicator (RSSI), Wide Range Signal and Power Measurement.

Parametrics

AD606JR absolute maximum ratings: (1)Supply Voltage VPOS:+9 V; (2)Internal Power Dissipation:600 mW; (3)Operating Temperature Range:0℃ to +70℃; (4)Storage Temperature Range:–65℃ to +150℃; (5)Lead Temperature Range (Soldering 60 sec):+300℃.

Features

AD606JR features: (1)Logarithmic Amplifier Performance; (2)–75 dBm to +5 dBm Dynamic Range; (3)≤1.5 nV/√Hz Input Noise; (4)Usable to >50 MHz; (5)37.5 mV/dB Voltage Output; (6)On-Chip Low-Pass Output Filter; (7)Limiter Performance; (8)61 dB Output Flatness over 80 dB Range; (9)638 Phase Stability at 10.7 MHz over 80 dB Range; (10)Adjustable Output Amplitude; (11)Low Power; (12)+5 V Single Supply Operation; (13)65 mW Typical Power Consumption; (14)CMOS-Compatible Power-Down to 325 mW typ; (15)<5 ms Enable/Disable Time.
